SUPPORTS ECC UDIMM MEMORY MODULES (OPERATE IN NON-ECC MODE)
- MAX. CAPACITY OF SYSTEM MEMORY: 32GB
SUPPORTS INTEL® EXTREME MEMORY PROFILE (XMP) 2.0
GRAPHICS
SUPPORTS INTEL® HD GRAPHICS BUILT-IN VISUALS : INTEL® QUICK SYNC VIDEO WITH AVC, MVC (S3D) AND MPEG-2 FULL HW ENCODE1, INTEL® INTRU™ 3D, INTEL® CLEAR VIDEO HD TECHNOLOGY, INTEL® INSIDER™, INTEL® HD GRAPHICS 510/530
PIXEL SHADER 5.0, DIRECTX 12
MAX. SHARED MEMORY 1024MB
DUAL GRAPHICS OUTPUT: SUPPORT DVI-D AND D-SUB PORTS BY INDEPENDENT DISPLAY CONTROLLERS
SUPPORTS DVI-D WITH MAX. RESOLUTION UP TO 1920X1200 @ 60HZ
SUPPORTS D-SUB WITH MAX. RESOLUTION UP TO 1920X1200 @ 60HZ
SUPPORTS ACCELERATED MEDIA CODECS: HEVC, VP8, VP9
SUPPORTS HDCP WITH DVI-D PORT
SUPPORTS FULL HD 1080P BLU-RAY (BD) PLAYBACK WITH DVI-D PORT
AUDIO
7.1 CH HD AUDIO (REALTEK ALC887 AUDIO CODEC)
SUPPORTS SURGE PROTECTION (ASROCK FULL SPIKE PROTECTION)
ELNA AUDIO CAPS
EXPANSION SLOTS
1 X PCI EXPRESS 3.0 X16 SLOT (PCIE1: X16 MODE)
1 X PCI EXPRESS 2.0 X1 SLOTS
STORAGE 4 X SATA3 6.0 GB/S CONNECTORS, SUPPORT NCQ, AHCI AND HOT PLUG
INTERNAL I/O CONNECTORS
1 X PRINT PORT HEADER
1 X COM PORT HEADER
1 X TPM HEADER
1 X CHASSIS INTRUSION AND SPEAKER HEADER
1 X CPU FAN CONNECTOR (4-PIN)
2 X CHASSIS FAN CONNECTORS (4-PIN)
1 X 24 PIN ATX POWER CONNECTOR
1 X 8 PIN 12V POWER CONNECTOR
1 X FRONT PANEL AUDIO CONNECTOR
2 X USB 2.0 HEADERS (SUPPORT 4 USB 2.0 PORTS) (SUPPORTS ESD PROTECTION (ASROCK FULL SPIKE PROTECTION))
1 X USB 3.0 HEADER (SUPPORTS 2 USB 3.0 PORTS) (SUPPORTS ESD PROTECTION (ASROCK FULL SPIKE PROTECTION))
BACK PANEL CONNECTORS
1 X PS/2 MOUSE PORT
1 X PS/2 KEYBOARD PORT
1 X D-SUB PORT
1 X DVI-D PORT
4 X USB 2.0 PORTS (SUPPORTS ESD PROTECTION (ASROCK FULL SPIKE PROTECTION))
2 X USB 3.0 PORTS (SUPPORTS ESD PROTECTION (ASROCK FULL SPIKE PROTECTION))
1 X RJ-45 LAN PORT WITH LED (ACT/LINK LED AND SPEED LED)
HD AUDIO JACKS: LINE IN / FRONT SPEAKER / MICROPHONE
LAN
PCIE X1 GIGABIT LAN 10/100/1000 MB/S
REALTEK RTL8111GR / RTL8111C
SUPPORTS LIGHTNING/ESD PROTECTION (ASROCK FULL SPIKE PROTECTION)
SUPPORTS LAN CABLE DETECTION
SUPPORTS PXE
FORM FACTOR
MICRO ATX FORM FACTOR: 8.9-IN X 7.2-IN, 22.6 CM X 18.3 CM
SOLID CAPACITOR DESIGN
H/W MONITORING
CPU/CHASSIS TEMPERATURE SENSING
CPU/CHASSIS FAN TACHOMETER
CPU/CHASSIS QUIET FAN (AUTO ADJUST CHASSIS FAN SPEED BY CPU TEMPERATURE)
CPU/CHASSIS FAN MULTI-SPEED CONTROL
CASE OPEN DETECTION
VOLTAGE MONITORING: +12V, +5V, +3.3V, CPU VCORE, DRAM, VPPM, PCH 1.0V, VCCIO
BIOS
64MB AMI UEFI LEGAL BIOS WITH MULTILINGUAL GUI SUPPORT
