SUPPORT FOR INTEL® CORE™ I7 PROCESSORS/INTEL® CORE™ I5 PROCESSORS/ INTEL® CORE™ I3 PROCESSORS/INTEL® PENTIUM® PROCESSORS/INTEL® CELERON® PROCESSORS IN THE LGA1155 PACKAGE
L3 CACHE VARIES WITH CPU
SOCKET 1155
CHIPSET INTEL H61
MEMORY SUPPORT
2 X 1.5V DDR3 DIMM SOCKETS SUPPORTING UP TO 16 GB OF SYSTEM MEMORY
DUE TO A WINDOWS 32-BIT OPERATING SYSTEM LIMITATION, WHEN MORE THAN 4 GB OF PHYSICAL MEMORY IS INSTALLED, THE ACTUAL MEMORY SIZE DISPLAYED WILL BE LESS THAN THE SIZE OF THE PHYSICAL MEMORY INSTALLED.
DUAL CHANNEL MEMORY ARCHITECTURE
SUPPORT FOR DDR3 1333/1066/800 MHZ MEMORY MODULES
SUPPORT FOR NON-ECC MEMORY MODULES
SUPPORT FOR EXTREME MEMORY PROFILE (XMP) MEMORY MODULES
TO SUPPORT XMP MEMORY, YOU MUST INSTALL AN INTEL® 22NM (IVY BRIDGE) CPU.
GRAPHICS 1 X D-SUB PORT
AUDIO
REALTEK® ALC887 CODEC
HIGH DEFINITION AUDIO
2/4/5.1/7.1-CHANNEL
TO CONFIGURE 7.1-CHANNEL AUDIO, YOU HAVE TO USE AN HD FRONT PANEL AUDIO MODULE AND ENABLE THE MULTI-CHANNEL AUDIO FEATURE THROUGH THE AUDIO DRIVER.
EXPANSION SLOTS
1 X PCI EXPRESS X16 SLOT, RUNNING AT X16
(THE PCI EXPRESS X16 SLOT CONFORMS TO PCI EXPRESS 3.0 STANDARD.)
WHETHER PCI EXPRESS 3.0 IS SUPPORTED DEPENDS ON CPU AND GRAPHICS CARD COMPATIBILITY.
2 X PCI EXPRESS X1 SLOTS
(THE PCI EXPRESS X1 SLOTS CONFORM TO PCI EXPRESS 2.0 STANDARD.)
STORAGE 4 X SATA 3GB/S CONNECTORS SUPPORTING UP TO 4 SATA 3GB/S DEVICES
USB 8 X USB 2.0/1.1 PORTS (4 PORTS ON THE BACK PANEL, 4 PORTS AVAILABLE THROUGH THE INTERNAL USB HEADERS)
INTERNAL I/O CONNECTORS
1 X 24-PIN ATX MAIN POWER CONNECTOR
1 X 4-PIN ATX 12V POWER CONNECTOR
4 X SATA 3GB/S CONNECTORS
1 X CPU FAN HEADER
1 X SYSTEM FAN HEADER
1 X FRONT PANEL HEADER
1 X FRONT PANEL AUDIO HEADER
1 X SPEAKER HEADER
2 X USB 2.0/1.1 HEADERS
1 X CHASSIS INTRUSION HEADER
1 X CLEAR CMOS JUMPER
BACK PANEL CONNECTORS
1 X PS/2 KEYBOARD PORT
1 X PS/2 MOUSE PORT
1 X D-SUB PORT
1 X PARALLEL PORT
1 X SERIAL PORT
4 X USB 2.0/1.1 PORTS
1 X RJ-45 PORT
3 X AUDIO JACKS (LINE IN, LINE OUT, MICROPHONE)
LAN REALTEK® GBE LAN CHIP (10/100/1000 MBIT)
FORM FACTOR MICRO ATX FORM FACTOR; 22.6CM X 17.4CM
H/W MONITORING
SYSTEM VOLTAGE DETECTION
CPU/SYSTEM TEMPERATURE DETECTION
CPU/SYSTEM FAN SPEED DETECTION
CPU OVERHEATING WARNING
CPU/SYSTEM FAN FAIL WARNING
CPU/SYSTEM FAN SPEED CONTROL
WHETHER THE CPU/SYSTEM FAN SPEED CONTROL FUNCTION IS SUPPORTED WILL DEPEND ON THE CPU/SYSTEM COOLER YOU INSTALL.
