SUPPORT FOR AN INTEL® CORE™ 2 EXTREME PROCESSOR/ INTEL® CORE™ 2 QUAD PROCESSOR/INTEL® CORE™ 2 DUO PROCESSOR/ INTEL® PENTIUM® PROCESSOR/INTEL® CELERON® PROCESSOR IN THE LGA 775 PACKAGE
(GO TO GIGABYTE'S WEBSITE FOR THE LATEST CPU SUPPORT LIST.)
L2 CACHE VARIES WITH CPU
FRONT SIDE BUS
1600(O.C.)/1333/1066/800 MHZ FSB
CHIPSET
NORTH BRIDGE: INTEL® G31 EXPRESS CHIPSET
SOUTH BRIDGE: INTEL® ICH7
MEMORY
2 X 1.8V DDR2 DIMM SOCKETS SUPPORTING UP TO 4 GB OF SYSTEM MEMORY
DUAL CHANNEL MEMORY ARCHITECTURE
SUPPORT FOR DDR2 1066(O.C.)/800/667 MHZ MEMORY MODULES
(GO TO GIGABYTE'S WEBSITE FOR THE LATEST MEMORY SUPPORT LIST.)
ONBOARD GRAPHICS
INTEGRATED IN THE NORTH BRIDGE
AUDIO
REALTEK ALC883 CODEC
HIGH DEFINITION AUDIO
2/4/5.1/7.1-CHANNEL (NOTE)
SUPPORT FOR S/PDIF OUT
SUPPORT FOR CD IN
NOTE: TO CONFIGURE 7.1-CHANNEL AUDIO, YOU NEED CONNECT WITH THE PORT OF HD AUDIO STANDARD VIA FRONT PANEL AND ENABLE THE MULTI-CHANNEL AUDIO FEATURE THROUGH THE AUDIO DRIVER.
LAN
AR8131 CHIP (10/100/1000 MBIT)
EXPANSION SLOTS
1 X PCI EXPRESS X16 SLOT
1 X PCI EXPRESS X1 SLOT
2 X PCI SLOTS
IDE ATA
SOUTH BRIDGE:
1 X IDE CONNECTOR SUPPORTING ATA-100/66/33 AND UP TO 2 IDE DEVICES
4 X SATA 3GB/S CONNECTORS SUPPORTING UP TO 4 SATA 3GB/S DEVICES
ITE IT8718 CHIP:
1 X FLOPPY DISK DRIVE CONNECTOR SUPPORTING UP TO 1 FLOPPY DISK DRIVE
USB
INTEGRATED IN THE SOUTH BRIDGE
UP TO 8 USB 2.0/1.1 PORTS (4 ON THE BACK PANEL, 4 VIA THE USB BRACKETS CONNECTED TO THE INTERNAL USB HEADERS)
