MAINBOARD (เมนบอร์ด) MSI MPG Z590 GAMING EDGE WIFI (ของใหม่) P11705
คุณสมบัติสินค้า:
SKU : P11705
หมวดหมู่ : สินค้า , MAINBOARD (เมนบอร์ด) ,
Share
- การรับประกันสินค้า
- ประกัน ARC 10/2024
- ประกันร้าน 30 วัน (ภายใต้เงื่อนไขการรับประกันสินค้า)
- สินค้ามือ 1, มีกล่อง, (กล่องนอก ชำรุด), (ของใหม่)
- ---------------------------------------------------------
- คุณสมบัติสินค้า
- BRAND MSI
- MODEL MPG Z590 GAMING EDGE WIFI
- CPU SUPPORT
- SUPPORTS 10TH GEN INTEL® CORE™ PROCESSORS, 11TH GEN INTEL® CORE™ PROCESSORS, PENTIUM® GOLD AND CELERON® PROCESSORS
- PROCESSOR SOCKET LGA1200
- SOCKET 1200
- CHIPSET INTEL Z590
- MEMORY SUPPORT
- 4X DDR4 MEMORY SLOTS, SUPPORT UP TO 128GB
- SUPPORTS 1R 2133/ 2666/ 2933 MHZ FOR 10TH GEN INTEL® CPU (BY JEDEC & POR)
- SUPPORTS 1R 2133/ 2666/ 2933/ 3200 MHZ FOR 11TH GEN INTEL® CPU (BY JEDEC & POR)
- MAX OVERCLOCKING FREQUENCY:
- 1DPC 1R MAX SPEED UP TO 5333 MHZ
- 1DPC 2R MAX SPEED UP TO 4700+ MHZ
- 2DPC 1R MAX SPEED UP TO 4400+ MHZ
- 2DPC 2R MAX SPEED UP TO 4000+ MHZ
- SUPPORTS DUAL-CHANNEL MODE
- SUPPORTS NON-ECC, UN-BUFFERED MEMORY
- SUPPORTS INTEL® EXTREME MEMORY PROFILE (XMP)
- GRAPHICS
- 1X HDMI 2.0B WITH HDR PORT, SUPPORTS A MAXIMUM RESOLUTION OF 4K 60HZ
- 1X DISPLAYPORT 1.4 PORT, SUPPORTS A MAXIMUM RESOLUTION OF 4K 60HZ
- MULTI GRAPHIC SUPPORT SUPPORTS AMD® CROSSFIRE™ TECHNOLOGY
- AUDIO
- REALTEK® ALC4080 CODEC
- 7.1-CHANNEL HIGH DEFINITION AUDIO
- SUPPORTS S/PDIF OUTPUT
- EXPANSION SLOTS
- 3X PCIE X16 SLOTS
- SUPPORT X16/X4/X4
- PCI_E1 (FROM CPU)
- SUPPORTS UP TO PCIE 4.0 FOR 11TH GEN INTEL® CPU
- SUPPORTS UP TO PCIE 3.0 FOR 10TH GEN INTEL® CPU
- PCI_E3 & PCI_E5 (FROM Z590 CHIPSET)
- SUPPORT UP TO PCIE 3.0
- 2X PCIE 3.0 X1 SLOTS (FROM Z590 CHIPSET)
- STORAGE
- 6X SATA 6GB/S PORTS (FROM Z590 CHIPSET)
- 3X M.2 SLOTS (KEY M)
- M2_1 SLOT (FROM CPU)
- AVAILABLE ONLY ON 11TH GEN INTEL® CPU
- SUPPORTS PCIE 4.0 X4
- SUPPORTS 2242/ 2260/ 2280/ 22110 STORAGE DEVICES
- M2_2* & M2_3** SLOT (FROM Z590 CHIPSET)
- SUPPORT UP TO PCIE 3.0 X4 AND SATA 6GB/S
- SUPPORTS 2242/ 2260/ 2280 STORAGE DEVICES
- INTEL® OPTANE™ MEMORY READY***
- SUPPORTS INTEL® SMART RESPONSE TECHNOLOGY FOR INTEL® CORE™ PROCESSORS
- PCI_E3 WILL BE UNAVAILABLE WHEN INSTALLING M.2 SSD IN THE M2_2 SLOT.
- ** SATA2 WILL BE UNAVAILABLE WHEN INSTALLING M.2 SATA SSD IN THE M2_2 SLOT.SATA5 & SATA6 WILL BE UNAVAILABLE WHEN INSTALLING M.2 SSD IN THE M2_3 SLOT.
- *** BEFORE USING INTEL® OPTANE™ MEMORY MODULES, PLEASE ENSURE THAT YOU HAVE UPDATED THE DRIVERS AND BIOS TO THE LATEST VERSION FROM MSI WEBSITE.
- USB
- INTEL® Z590 CHIPSET
- 1X USB3.2 GEN2X2 20GBPS PORT (TYPE-C PORT ON THE BACK PANEL)
- 4X USB 3.2 GEN 1 5GBPS PORTS (2 TYPE-A PORT ON THE BACK PANEL AND 2 PORTS ARE AVAILABLE THROUGH THE INTERNAL CONNECTORS)
- 4X USB 3.2 GEN 2 10GBPS PORTS (1 TYPE-C INTERNAL CONNECTOR AND 3 TYPE-A PORTS ON THE BACK PANEL)
- HUB-GL850G
- 6X USB 2.0 PORTS (2 TYPE-A PORT ON THE BACK PANEL AND 4 PORTS ARE AVAILABLE THROUGH THE INTERNAL CONNECTORS)
- INTERNAL I/O CONNECTORS
- 1 X 24-PIN ATX MAIN POWER CONNECTOR
- 2 X 8-PIN ATX 12V POWER CONNECTORS
- 1 X 6-PIN PCIE POWER CONNECTOR
- 6 X SATA 6GB/S CONNECTORS
- 3 X M.2 SLOTS (M-KEY)
- 1 X USB 3.2 GEN 2 10GBPS TYPE-C PORT
- 1 X USB 3.2 GEN 1 5GBPS CONNECTOR (SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 5GBPS PORTS)
- 2 X USB 2.0 CONNECTORS (SUPPORTS ADDITIONAL 4 USB 2.0 PORTS)
- 1 X 4-PIN CPU FAN CONNECTOR
- 1 X 4-PIN WATER-PUMP FAN CONNECTOR
- 6 X 4-PIN SYSTEM FAN CONNECTORS
- 1 X FRONT PANEL AUDIO CONNECTOR
- 2 X SYSTEM PANEL CONNECTORS
- 1 X CHASSIS INTRUSION CONNECTOR
- 1 X CLEAR CMOS JUMPER
- 1 X TPM MODULE CONNECTOR
- 1 X TBT CONNECTOR (SUPPORTS RTD3)
- BACK PANEL CONNECTORS
- 1 X DISPLAYPORT
- 2 X USB 3.2 GEN 1 5GBPS TYPE-A
- 1 X 2.5G LAN
- 2 X WI-FI/BLUETOOTH
- 5 X AUDIO CONNECTORS
- 1 X FLASH BIOS BUTTON
- 2 X USB 2.0
- 1 X HDMI
- 3 X USB 3.2 GEN 2 10GBPS TYPE-A
- 1 X USB 3.2 GEN 2X2 20GBPS TYPE-C
- 1 X OPTICAL S/PDIF OUT
- LAN 1 X INTEL® I225V 2.5GBPS LAN CONTROLLER
- WIRELESS DATA NETWORK
- INTEL® WI-FI 6E AX210
- THE WIRELESS MODULE IS PRE-INSTALLED IN THE M.2 (KEY-E) SLOT
- SUPPORTS MU-MIMO TX/RX, 2.4GHZ/ 6GHZ* (160MHZ) UP TO 2.4GBPS
- SUPPORTS 802.11 A/ B/ G/ N/ AC/ AX
- SUPPORTS BLUETOOTH 5.2**, FIPS, FISMA
- WI-FI 6E 6GHZ MAY DEPEND ON EVERY COUNTRY’S REGULATIONS AND WILL BE READY IN WIN10 21H1.
- ** BLUETOOTH 5.2 WILL BE READY IN WIN10 21H1.
- FORM FACTOR
- ATX FORM FACTOR
- 12 IN. X 9.6 IN. (30.5 CM X 24.4 CM)
- H/W MONITORING N/A
- BIOS N/A
- SPECIAL FEATURES N/A
- SOFTWARE FEATURES N/A
- OPERATING SYSTEM SUPPORT
- SUPPORT FOR WINDOWS® 10 64-BIT
- ---------------------------------------------------------
- เงื่อนไขการรับประกันสินค้า
- คืนสินค้าได้ภายใน 7 วัน (นับจากวันที่ได้รับสินค้า)
- สินค้าต้องอยู่ในสภาพสมบูรณ์ไม่แตก หัก บิ่น ไหม้ หรือโดนน้ำ
- วอยด์รับประกันต้องไม่ชำรุด ฉีกขาด
- ต้องมีเหตุผลอันสมควรในการขอคืนสินค้า
